Specification
- Local Unit
1) Host Connection
2) Multiplatform support: Windows 2000/XP/Vista/Windows7/Server 2000/2003/2008, Solaris, Linux, FreeBSD, and MAC OS 9/10.
3) Male/Female 15-pin HD connector for computer connection.
4) Optional stereo audio support - 3.5mm stereo plug.
5) Local Access
6) Crisp and clear 1920x1440 video resolution.
7) Female 15-pin HD connector for local VGA monitor.
8) Optional stereo audio support - 3.5mm stereo jack.
- Remote Unit
1) Supports resolutions up to 1920x1440; refer to the resolution chart below for resolutions at different lengths.
2) Female 15-pin HD connector.
3) Optional 3.5mm stereo audio connection.
- Video Quality Adjustment
1) Video quality adjustment for different lengths of CAT5/5e/6 cable is done manually for the video-only extender, and automatically for audio/video extender.
- Environmental
1) Operating temperature: 32°F to 100°F (0°C to 38°C).
2) Storage temperature: -20°F to 140°F (-30°C to 60°C).
3) Operating and Storage Relative Humidity: 17 - 90% non-condensing RH.
- Dimensions
1) L*W*H (mm): 95*97*28mm(Sender)
95*97*28mm(Receiver)
2) Weight(Kg):0.9KG
- Power
1) 220 or 110 VAC at 50 or 60 Hz via AC adapter (Included).
2) Power Consumption: 6W (each - local and remote unit).
3) Use the PWR-48V-9V0,6A or PWR-12V-9V0,6A DC-DC power converter to install the local unit in a Telecom environment. Packing Contents
1. Main Unit. 1 unit VGA Cat5e/6 Extender
2. 2pcs Power Adapter
3. 1pcs User Manual |
